The 48V 3.5kWh (73 Amp Hour) Pylontech US3000C LiFePO4 battery is a server rack-mounted, highly efficient energy storage solution for off grid tiny homes and cabins, as well as ESS and battery backup hybrid renewable energy systems.
The 48V US3000C features:
Internal BMS with following protections
Over and under voltage
High and low temperature
Over current and short circuit
Cell balancing and operation recording
Soft start for inverter pre-charge
Built in RS485 and CAN communication compatible with Victron monitoring and control systems
Compact size server rack style mounting, making them easy to utilize in large and small systems
UL1973/1642/9540A certified
Continuous discharge rate of 37A with a 60s peak of 89A and a 15s peak of 200A
Up to 16 batteries can be connected in a single string and up to 6 strings for a total of 96 batteries (336kWh max capacity)
Easily combine batteries with included connection cables
Cycle life of 6000+
Rated capacity of 3,552Wh (73Ah)
48V nominal for higher efficiency
10 Year warranty
95% depth of discharge
High and low voltage protection
High and low temperature protection
Built in pre charge resistor for easy inverter commissioning and ESS protection
The 48V US3000C is an excellent option for off grid and ESS systems. With its built-in BMS, installation is very easy, while still allowing for advanced closed loop communications between the battery bank and Victron systems.
This server rack style lithium battery is compact, energy dense, and easily scalable. Common applications include cabins, tiny homes, mobile businesses and hybrid generator systems.
Connected to aCerbo GX, Pylontech battery bank data will automatically populate in the device list, including state of charge, voltage, temperature, and energy throughput. Since this data is available directly from the battery, an external shunt or battery monitor is not required.
Collaboration between Pylontech and Victron R&D teams has confirmed that these systems will integrate seamlessly, and Victron lists Pylontech on their certified compatible battery list.
